32 Amp. AC-1, 18 Amp. AC-3
 Normally Open (N.O.) contacts 600V
 32A. Incandescent, LED or resistive load
 20A. Ballast, Motor 7.5HP @480V
Auxiliary contact  1NO/1NC
Power Lug Terminal Capacity AWG # 6
 Coil 110/120VAC
  Details*        Specifications

50 Amp. AC-1, 32 Amp. AC-3
 Normally Open (N.O.) contacts 600V
 50A. Incandescent, LED or resistive load
 32A. Motor control, 20HP@ 480VAC
Auxiliary contact  1NO/1NC
Power Lug Terminal Capacity AWG # 4
Coil 110/120VAC
Details*     Specifications

.

60 Amp.  4 Pole  (Silent Operation)
 Normally Open (N.O.) contacts
 For 120/220/277/Rated 500V,
 7.5HP @240V, 15HP @460V
 60A. Ballast, 7 KW@ 220VAC
Dimension: 2.2w x 3.3h x 2.5d inch
 40Amp AC-1,  30Amp AC-3
Power Lug Terminal Capacity AWG # 4
Coil 110/120VAC
Specifications    add DIN rail



60Amp.  4 Pole N/C  (Silent Operation)
 Normally closed (N.C.) contacts
For 120/220/277/Rated 400V,
60A. Incandescent or resistive load AC1
32A. Ballast and General purpose  AC3
Power indicator, DIN mount
Dim: 2.2 x 3.5 x 2.5 in (55 x 90 x 70 mm)
Power Lug Terminal Capacity AWG # 4
Coil 110/120VAC
Specifications         add DIN rail

933181   85 Amp. 3 Pole Contactor
Mechanical Held Control
Rated 600V,  2 N/O, 2 N/C Auxiliary Contacts
 40HP @240V, 60HP @460V
 Resistive or LED Load 100Amp
 135Amp AC-1,  85Amp AC-3
Dimension: 3.3w x 5.3h x 5.1d inch
Power Lug Terminal Capacity AWG #00

■ Momentary closure of the input terminals
will latch the Contactor ON,
■ Subsequent closure will unlatch the Contactor OFF

• Retains status on power failure
 Coil 110/120VAC       (1) Special Order

MC3224DC    3 POLE

50 Amp. AC-1, 32 Amp. AC-3
 Normally Open (N.O.) contacts 600V
 50A. Incandescent, LED or resistive load
 32A. Motor control, 20HP@ 480VAC
Auxiliary contact  1NO/1NC
Dimension: 3.3w x 5.3h x 4.1d inch
Power Lug Terminal Capacity AWG # 4
Coil 24VDC

 MC6524DC  3 Pole

100Amp AC-1,  65Amp AC-3
 Normally Open (N.O.) contacts
 Rated 600V,  2 N/O, 2 N/C Auxiliary Contacts
 20HP @240V, 75HP @460V
 Dimension: 3.3w x 5.3h x 5.1d inch
 100Amp AC-1,  65Amp AC-3
Power Lug Terminal Capacity AWG #00
Coil 24VDC

100 Amp. 4 Pole  Slim contactor
Normally Open (N.O.) contacts
For 120/220/277/Rated 500V,
50A. Ballast, 10 KW@ 220VAC, 15KW@277V
100A  AC-1,  40A. AC-3
40A, 24VDC, DC Switching
Power indicator, DIN mount
Dim: 110 x 81 x 68 mm) Dimensions
Power Lug Terminal Capacity AWG # 2/0
120VAC coil

100 Amp. 4 Pole  Slim contactor
Mechanical Held Control
50A. Ballast, 10 KW@ 220VAC, 15KW@277V
100A  AC-1,  40A. AC-3
40A, 24VDC, DC Switching
Resistive or LED Load 100Amp
Power indicator, DIN mount
Dim: 120 x 81 x 68 mm)
Power Lug Terminal Capacity AWG # 2/0

■ Momentary closure of the input terminals
will latch the Contactor ON,
■ Subsequent closure will unlatch the Contactor OFF

• Retains status on power failure
 Coil 110/120VAC   (1) Special Order

933021 Miniature Contactor
20Amp, 3 Pole, 120VAC Coil
2HP @240V, 7.5HP @460V
1HP @120V,  20Amp AC-1, 12Amp. AC-3
Screw Clamp Terminals, 600V, 1 N.O. Aux.,
AC Coil Current Inrush 32VA, Sealed 6VA
Dim: 1.7 x 2.5 x 2.3 in (45 x 64 x 58 mm)
Power Lug Terminal Capacity AWG # 8

933020 Miniature Contactor
20Amp, 3 Pole, 12VDC Coil
2HP @240V, 7.5HP @460V
1HP @120V,  20Amp AC-1, 12Amp. AC-3
Screw Clamp Terminals, 600V, 1 N.O. Aux.,
DC Coil Current Inrush/Sealed  250mA
Dim: 1.7 x 2.5 x 2.3 in (45 x 64 x 58 mm)
Power Lug Terminal Capacity AWG # 8

 DIN rail 10cm (3.98inch)

DIN rail 20cm (7.87inch)
